- TPS6500x, 6500xx Datasheet
TPS6500x, 6500xx Datasheet Datasheet
Datasheet specifications
| Datasheet's name | TPS6500x, 6500xx Datasheet |
|---|---|
| File size | 2686.271 KB |
| File type | |
| Number of pages | 40 |
Download Datasheet TPS6500x, 6500xx Datasheet |
Download Datasheet |
|---|
Other documentations
TPS65000EVM Guide 15 pages
Technical specifications
- Series: -
- Board Type: Fully Populated
- Outputs and Type: 3, Non-Isolated
- Current - Output: 600mA, 300mA, 300mA
- Frequency - Switching: 2.25MHz
- Main Purpose: DC/DC, Step Down with LDO
- Part Status: Active
- Base Part Number: TPS650
- Utilized IC / Part: TPS65000
- Voltage - Input: 3.3V ~ 6V
- Manufacturer: Texas Instruments
- Voltage - Output: 1.2V, 1.8V, 2.8V
- Supplied Contents: Board(s)
- Regulator Topology: Buck
- detail: TPS65000 - DC/DC, Step Down with LDO 3, Non-Isolated Outputs Evaluation Board
