دیتاشیت MCP23009-E/MG

MCP23009,23S09

مشخصات دیتاشیت

نام دیتاشیت MCP23009,23S09
حجم فایل 982.122 کیلوبایت
نوع فایل pdf
تعداد صفحات 52

دانلود دیتاشیت MCP23009,23S09

MCP23009,23S09 Datasheet

مشخصات

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/I/O Expanders
  • Datasheet: Microchip Tech MCP23009-E/MG
  • Interface: I2C
  • Output Type: Open Drain
  • Number of I/O: 8
  • Supply Voltage: 1.8V~5.5V
  • Clock Frequency: 3.4MHz
  • Interrupt Output: 有中断输出
  • Output Sink Current: 25mA
  • Operating Temperature: -40°C~+125°C
  • Output Source current: 25mA
  • Package: QFN-16-EP(3x3)
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Features: POR
  • Current - Output Source/Sink: 25mA
  • Voltage - Supply: 1.8V ~ 5.5V
  • Mounting Type: Surface Mount
  • Package / Case: 16-VFQFN Exposed Pad
  • Supplier Device Package: 16-QFN-EP (3x3)
  • Base Part Number: MCP23009
  • detail: I/O Expander 8 I²C 3.4MHz 16-QFN-EP (3x3)
