دیتاشیت MIC28514T-E/PHA
مشخصات دیتاشیت
| نام دیتاشیت |
MIC28514
|
| حجم فایل |
1102.028
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
31
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Microchip Tech MIC28514T-E/PHA
-
Output Type:
Adjustable
-
Input Voltage:
4.5V~75V
-
Output Voltage:
0.6V~32V
-
Number of Outputs:
1
-
Switching Frequency:
800kHz
-
Output Current (Max):
5A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
Yes
-
Package:
QFN-32-EP(6x6)
-
Manufacturer:
Microchip Tech
-
Series:
Hyper Speed Control®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
4.5V
-
Voltage - Input (Max):
75V
-
Voltage - Output (Min/Fixed):
0.6V
-
Voltage - Output (Max):
32V
-
Current - Output:
5A
-
Frequency - Switching:
270kHz ~ 800kHz
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount, Wettable Flank
-
Package / Case:
32-PowerVQFN
-
Supplier Device Package:
32-VQFN (6x6)
-
Base Part Number:
MIC28514
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 5A 32-PowerVQFN
