CSD95372BQ5MC Datasheet دیتاشیت

CSD95372BQ5MC Datasheet

مشخصات دیتاشیت

نام دیتاشیت CSD95372BQ5MC Datasheet
حجم فایل 874.505 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

مشاهده دیتاشیت CSD95372BQ5MC Datasheet

دانلود دیتاشیت

سایر مستندات

CSD95372BQ5MC 13 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Datasheet: Texas Instruments CSD95372BQ5MC
  • Package: SON-12-EP(5x6)
  • Manufacturer: Texas Instruments
  • Series: NexFET™
  • Rds On (Typ): -
  • Technology: Power MOSFET
  • Base Part Number: CSD95372
  • Supplier Device Package: 12-VSON (5x6)
  • Package / Case: 12-PowerTFDFN
  • Fault Protection: Current Limiting, Over Temperature, Shoot-Through, Short Circuit, UVLO
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Load Type: Inductive
  • Applications: Synchronous Buck Converters
  • Voltage - Load: 4.5V ~ 16V
  • Current - Peak Output: 90A
  • Voltage - Supply: 4.5V ~ 5.5V
  • Features: Bootstrap Circuit, Status Flag
  • Packaging: Cut Tape (CT)
  • Output Configuration: Half Bridge
  • Interface: PWM
  • Current - Output / Channel: 60A
  • detail: Half Bridge Driver Synchronous Buck Converters Power MOSFET 12-VSON (5x6)
