SN74LVC1G34 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN74LVC1G34
|
|
حجم فایل
|
2764.72
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
46
|
مشخصات فنی
-
RoHS:
true
-
Category:
Logic ICs/Buffer/Driver/Transceiver
-
Datasheet:
Texas Instruments SN74LVC1G34DBVRG4
-
Package:
SOT-23-5
-
Manufacturer:
Texas Instruments
-
Series:
74LVC
-
Package / Case:
SC-74A, SOT-753
-
Number of Bits per Element:
1
-
Number of Elements:
1
-
Supplier Device Package:
SOT-23-5
-
Part Status:
Active
-
Current - Output High, Low:
32mA, 32mA
-
Mounting Type:
Surface Mount
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Base Part Number:
SN74LVC1G
-
Voltage - Supply:
1.65V ~ 5.5V
-
Packaging:
Cut Tape (CT)
-
Input Type:
-
-
Logic Type:
Buffer, Non-Inverting
-
Output Type:
Push-Pull
-
detail:
Buffer, Non-Inverting 1 Element 1 Bit per Element Push-Pull Output SOT-23-5
