MCP4822T-E/MS دیتاشیت

MCP4822T-E/MS

مشخصات دیتاشیت

نام دیتاشیت MCP4822T-E/MS
حجم فایل 108.595 کیلوبایت
نوع فایل pdf
تعداد صفحات 50

دانلود دیتاشیت MCP4822T-E/MS

دانلود دیتاشیت

سایر مستندات

MCP4802,4812,4822 Datasheet 50 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Microchip Tech MCP4822T-E/MS
  • Interface: SPI
  • Resolution: 12Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 4.5us
  • Supply Voltage: 2.7V~5.5V
  • Integral nonlinearity: ±4LSB;±0.25LSB
  • Operating Temperature: -40°C~+125°C
  • Package: MSOP-8
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 12
  • Number of D/A Converters: 2
  • Differential Output: No
  • Data Interface: SPI
  • Reference Type: Internal
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±4, ±0.25
  • Architecture: String DAC
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 8-MSOP
  • Mounting Type: Surface Mount
  • Base Part Number: MCP4822
  • detail: 12 Bit Digital to Analog Converter 2 8-MSOP
