دیتاشیت 2N6661
مشخصات دیتاشیت
| نام دیتاشیت |
2N6661
|
| حجم فایل |
463.617
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Microchip Tech 2N6661
-
Package:
TO-5
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
90V
-
Current - Continuous Drain (Id) @ 25°C:
350mA (Tj)
-
Drive Voltage (Max Rds On, Min Rds On):
5V, 10V
-
Rds On (Max) @ Id, Vgs:
4Ohm @ 1A, 10V
-
Vgs(th) (Max) @ Id:
2V @ 1mA
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
50pF @ 24V
-
FET Feature:
-
-
Power Dissipation (Max):
6.25W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
TO-39
-
Package / Case:
TO-205AD, TO-39-3 Metal Can
-
detail:
N-Channel 90V 350mA (Tj) 6.25W (Tc) Through Hole TO-39
