OEM PoE Midspan Brochure Datasheet
Datasheet specifications
| Datasheet's name | OEM PoE Midspan Brochure |
|---|---|
| File size | 2483.691 KB |
| File type | |
| Number of pages | 12 |
Download Datasheet OEM PoE Midspan Brochure |
Download Datasheet |
|---|
Other documentations
PD3501G Datasheet 2 pages
PD-3501G User Guide 2 pages
Technical specifications
- Manufacturer: Microchip Technology
- Series: PowerDsine®
- Part Status: Active
- Type: Midspan Injector
- Voltage - Input: 90 ~ 264 VAC
- Number of Ports: 1
- Voltage - Output: 48V
- Current - Output: 320mA
- Power (Watts) - Per Port: 15.4W
- Compliance: IEEE802.3af
- Data Rate: 10/100/1000 Mbps
- Features: -
- Operating Temperature: 0°C ~ 40°C
- Efficiency: -
- Mounting Type: Desktop
- Size / Dimension: 5.50" L x 2.09" W x 1.28" H (140.0mm x 53.0mm x 32.5mm)
- Approval Agency: CE, cUL, GS, UL
- Note: -
- Input Connector: IEC 320-C14 (Power), RJ45 (Data)
- Output Connector: RJ45 (Data, Power)
- Weight: 0.441 lb (200.03 g)
- detail: 48V Power Over Ethernet (POE) 1 Port Midspan Injector 10/100/1000 Mbps Data Rate
