TPS71025P دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS71025P
|
|
حجم فایل
|
83.663
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
25
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS71025P
-
Output Current:
500mA
-
Output Voltage:
2.5V
-
Dropout Voltage:
0.4V@(500mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
10V
-
Operating Temperature:
0°C~+125°C
-
Quiescent Current (Ground Current):
390uA
-
Package:
PDIP-8
-
Manufacturer:
Texas Instruments
-
Voltage Dropout (Max):
0.4V @ 500mA
-
Current - Supply (Max):
540µA
-
Current - Output:
500mA
-
Current - Quiescent (Iq):
390µA
-
Voltage - Input (Max):
10V
-
Base Part Number:
TPS710
-
Package / Case:
8-DIP (0.300", 7.62mm)
-
Voltage - Output (Max):
-
-
Output Configuration:
Positive
-
Series:
-
-
Supplier Device Package:
8-PDIP
-
PSRR:
59dB ~ 54dB (120Hz)
-
Part Status:
Active
-
Mounting Type:
Through Hole
-
Control Features:
Enable, Power Good
-
Protection Features:
Over Temperature
-
Voltage - Output (Min/Fixed):
2.5V
-
Number of Regulators:
1
-
Packaging:
Tube
-
Output Type:
Fixed
-
detail:
Linear Voltage Regulator IC 1 Output 500mA 8-PDIP
