TS5A3167YZPR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TS5A3167YZPR
|
|
حجم فایل
|
59.734
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
36
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TS5A3167YZPR
-
Turn-on time:
7.5ns
-
Turn-off time:
11ns
-
Supply Voltage:
1.65V~5.5V
-
Switch Circuit:
SPST(SPST)-Normally closed
-
Number of Channels:
1
-
On-State Resistance (Max):
900mΩ
-
Package:
BGA-5
-
Manufacturer:
Texas Instruments
-
Charge Injection:
6pC
-
Voltage - Supply, Dual (V±):
-
-
Crosstalk:
-
-
Base Part Number:
TS5A316
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Switch Time (Ton, Toff) (Max):
7.5ns, 11ns
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Package / Case:
5-XFBGA, DSBGA
-
Channel Capacitance (CS(off), CD(off)):
19pF, 18pF
-
Channel-to-Channel Matching (ΔRon):
-
-
Supplier Device Package:
5-DSBGA, 5-WCSP (1.4x0.9)
-
Series:
-
-
Current - Leakage (IS(off)) (Max):
20nA
-
Number of Circuits:
1
-
Part Status:
Active
-
Mounting Type:
Surface Mount
-
Voltage - Supply, Single (V+):
1.65V ~ 5.5V
-
-3db Bandwidth:
150MHz
-
Packaging:
Cut Tape (CT)
-
detail:
1 Circuit IC Switch 1:1 900mOhm 5-DSBGA, 5-WCSP (1.4x0.9)
