TS5A2053 دیتاشیت

TS5A2053

مشخصات دیتاشیت

نام دیتاشیت TS5A2053
حجم فایل 980.877 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

مشاهده دیتاشیت TS5A2053

دانلود دیتاشیت

سایر مستندات

TS5A2053 Errata 10 pages

مشخصات فنی

  • Switch Circuit: SPDT
  • Charge Injection: 3pC
  • Voltage - Supply, Dual (V±): -
  • Crosstalk: -68dB @ 10MHz
  • Base Part Number: TS5A205
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Switch Time (Ton, Toff) (Max): 6.8ns, 4.1ns
  • Multiplexer/Demultiplexer Circuit: 2:1
  • Package / Case: 8-LSSOP, 8-MSOP (0.110", 2.80mm Width)
  • Channel Capacitance (CS(off), CD(off)): 6pF, 9.5pF
  • Channel-to-Channel Matching (ΔRon): 800mOhm
  • Supplier Device Package: SM8 (SSOP)
  • Series: -
  • Current - Leakage (IS(off)) (Max): 100nA
  • Number of Circuits: 1
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Voltage - Supply, Single (V+): 1.65V ~ 5.5V
  • Manufacturer: Texas Instruments
  • -3db Bandwidth: 330MHz
  • On-State Resistance (Max): 13.8Ohm
  • Packaging: Cut Tape (CT)
  • detail: 1 Circuit IC Switch 2:1 13.8Ohm SM8 (SSOP)
