دیتاشیت LM239AQDRQ1
مشخصات دیتاشیت
| نام دیتاشیت |
LM239A-Q1
|
| حجم فایل |
211.997
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Comparators
-
Datasheet:
Texas Instruments LM239AQDRQ1
-
Output Type:
开集;轨到轨
-
Supply Voltage:
2V~36V;1V~18V
-
Number of Elements:
-
-
Operating Temperature:
-40°C~+125°C
-
Input Bias Current (Ib):
0.25uA
-
Input Offset Voltage (Vos):
2.5mV
-
Input Hysteresis Voltage (Vhys):
-
-
Common Mode Rejection Ratio (CMRR):
-
-
Package:
SOP-14
-
Manufacturer:
Texas Instruments
-
Series:
Automotive, AEC-Q100
-
Type:
Differential
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Voltage - Input Offset (Max):
2.5mV @ 30V
-
Current - Output (Typ):
20mA
-
Part Status:
Active
-
Base Part Number:
LM239
-
Mounting Type:
Surface Mount
-
Voltage - Supply, Single/Dual (±):
2V ~ 36V, ±1V ~ 18V
-
Propagation Delay (Max):
-
-
Current - Input Bias (Max):
0.25µA @ 5V
-
Hysteresis:
-
-
Packaging:
Digi-Reel®
-
CMRR, PSRR (Typ):
-
-
Current - Quiescent (Max):
2mA
-
Supplier Device Package:
14-SOIC
-
detail:
Comparator Differential CMOS, MOS, Open-Collector, TTL 14-SOIC
