SN74AUC1G00 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN74AUC1G00
|
|
حجم فایل
|
1224.504
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
20
|
مشخصات فنی
-
RoHS:
true
-
Series:
74AUC
-
Category:
Logic ICs/Gates
-
Datasheet:
Texas Instruments SN74AUC1G00YZPR
-
Sink Current:
9mA
-
Source Current:
9mA
-
Supply Voltage:
0.8V~2.7V
-
Logic Gate Type:
NAND Gates
-
Number of Channels:
1
-
Low Level Range (VIL):
0V~0.7V
-
Operating Temperature:
-40°C~+85°C
-
High Level Range (VIH):
1.7V
-
Propagation Delay Time:
2ns@2.5V,30pF
-
Quiescent Current (Max):
10uA
-
Package:
BGA-5
-
Manufacturer:
Texas Instruments
-
Current - Quiescent (Max):
10µA
-
Package / Case:
5-XFBGA, DSBGA
-
Logic Level - High:
1.7V
-
Number of Circuits:
1
-
Number of Inputs:
2
-
Features:
-
-
Current - Output High, Low:
9mA, 9mA
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
5-DSBGA, 5-WCSP (1.4x0.9)
-
Logic Type:
NAND Gate
-
Max Propagation Delay @ V, Max CL:
2ns @ 2.5V, 30pF
-
Voltage - Supply:
0.8V ~ 2.7V
-
Packaging:
Cut Tape (CT)
-
Base Part Number:
SN74AUC1
-
Part Status:
Active
-
Logic Level - Low:
0V ~ 0.7V
-
detail:
NAND Gate IC 1 Channel 5-DSBGA, 5-WCSP (1.4x0.9)
