SN74HC377NG4 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت SN74HC377NG4	دانلود دیتاشیت

RoHS: true
Type: -
Series: -
Category: Logic ICs/Flip Flops
Function: -
Datasheet: Texas Instruments SN74HC377NG4
Output Type: -
Trigger Type: -
Package: PDIP-20
Manufacturer: Texas Instruments
Package / Case: 20-DIP (0.300", 7.62mm)
Current - Output High, Low: 5.2mA, 5.2mA
Number of Elements: 1
Clock Frequency: 64MHz
Current - Quiescent (Iq): 8µA
Part Status: Active
Number of Bits per Element: 8
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 85°C (TA)
Max Propagation Delay @ V, Max CL: 27ns @ 6V, 50pF
Input Capacitance: 3pF
Voltage - Supply: 2V ~ 6V
Packaging: Tube
Base Part Number: SN74HC3
Supplier Device Package: 20-PDIP
detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-DIP (0.300", 7.62mm)
