دیتاشیت RN4871-I/RM130
مشخصات دیتاشیت
| نام دیتاشیت | RN4870,71 Datasheet |
|---|---|
| حجم فایل | 2217.895 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 51 |
دانلود دیتاشیت RN4870,71 Datasheet |
RN4870,71 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: IoT/Communication Modules/Bluetooth Modules
- Core IC: RN4871
- Datasheet: Microchip Tech RN4871-I/RM130
- Support Interface: I2C;AIO;PIO;PWM;SPI;UART
- Output Power (Max): 0dBm
- Package: SMD-16P
- Manufacturer: Microchip Tech
- Series: -
- Part Status: Active
- RF Family/Standard: Bluetooth
- Protocol: Bluetooth v5.0
- Modulation: GFSK
- Frequency: 2.4GHz
- Data Rate: 10kbps
- Power - Output: 0dBm
- Sensitivity: -90dBm
- Serial Interfaces: I²C, AIO, PIO, PWM, SPI, UART
- Antenna Type: Integrated, Chip
- Utilized IC / Part: RN4871
- Memory Size: 256kB Flash, 32kB ROM, 24kB SRAM
- Voltage - Supply: 1.9V ~ 3.6V
- Current - Receiving: 13mA
- Current - Transmitting: 13mA
- Mounting Type: Surface Mount
- Operating Temperature: -40°C ~ 85°C
- Package / Case: 16-SMD Module
- Firmware Version: 1.3.0
- Base Part Number: RN4871
- detail: Bluetooth Bluetooth v5.0 Transceiver Module 2.4GHz Integrated, Chip Surface Mount
