TLV70012QDCKRQ1 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TLV70012QDCKRQ1
|
|
حجم فایل
|
95.869
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
24
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TLV70012QDCKRQ1
-
Output Current:
300mA
-
Output Voltage:
1.2V
-
Dropout Voltage:
0.25V@(200mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C@(Ta)
-
Quiescent Current (Ground Current):
55uA
-
Power Supply Rejection Ratio (PSRR):
68dB@(1kHz)
-
Package:
SC-70-5
-
Manufacturer:
Texas Instruments
-
Voltage Dropout (Max):
0.25V @ 200mA
-
Current - Supply (Max):
270µA
-
Current - Output:
300mA
-
Current - Quiescent (Iq):
55µA
-
Voltage - Input (Max):
5.5V
-
Base Part Number:
TLV700
-
Package / Case:
5-TSSOP, SC-70-5, SOT-353
-
Voltage - Output (Max):
-
-
Output Configuration:
Positive
-
Series:
Automotive, AEC-Q100
-
Supplier Device Package:
SC-70-5
-
PSRR:
68dB (1kHz)
-
Part Status:
Active
-
Mounting Type:
Surface Mount
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
-
Voltage - Output (Min/Fixed):
1.2V
-
Number of Regulators:
1
-
Packaging:
Digi-Reel®
-
Output Type:
Fixed
-
detail:
Linear Voltage Regulator IC 1 Output 300mA SC-70-5
