AD847JNZ Datasheet

AD847JNZ

Datasheet specifications

Datasheet's name AD847JNZ
File size 251.024 KB
File type pdf
Number of pages 12

Download Datasheet AD847JNZ

Download Datasheet

Other documentations

AD847 12 pages

AD847AQ 12 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Analog Devices AD847JNZ
  • -3db Bandwidth: -
  • Output Current: 32mA
  • Number of Circuits: 1
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 3.3uA
  • Gain Bandwidth Product(GBP): 50MHz
  • Package: PDIP-8
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Amplifier Type: General Purpose
  • Output Type: -
  • Slew Rate: 300V/µs
  • Gain Bandwidth Product: 50MHz
  • Current - Input Bias: 3.3µA
  • Voltage - Input Offset: 500µV
  • Current - Supply: 5.3mA
  • Current - Output / Channel: 32mA
  • Voltage - Supply, Single/Dual (±): ±4.5V ~ 18V
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: AD847
  • detail: General Purpose Amplifier 1 Circuit 8-PDIP
