- دیتاشیت MIC5232-3.3YD5-TR
MIC5232-3.3YD5-TR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MIC5232-3.3YD5-TR |
|---|---|
| حجم فایل | 89.643 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
دانلود دیتاشیت MIC5232-3.3YD5-TR |
دانلود دیتاشیت |
|---|
سایر مستندات
MIC5232 10 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech MIC5232-3.3YD5-TR
- Output Type: Fixed
- Output Current: 10mA
- Output Voltage: 3.3V
- Dropout Voltage: 300mV@(10mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 7V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 3uA
- Power Supply Rejection Ratio (PSRR): 55dB@(10Hz),35dB@(1kHz)
- Package: TSOT-23-5
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 7V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.3V @ 10mA
- Current - Output: 10mA
- Current - Quiescent (Iq): 3µA
- PSRR: 55dB ~ 35dB (10Hz ~ 1kHz)
- Control Features: Enable
- Protection Features: Reverse Polarity
- Mounting Type: Surface Mount
- Package / Case: SOT-23-5 Thin, TSOT-23-5
- Supplier Device Package: TSOT-23-5
- Base Part Number: MIC5232
- detail: Linear Voltage Regulator IC 1 Output 10mA TSOT-23-5
