MAX4596DCKR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MAX4596DCKR	دانلود دیتاشیت

MAX4596 21 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments MAX4596DCKR
Turn-on time: 35ns
Turn-off time: 40ns
Supply Voltage: 2.4V~5.5V
Switch Circuit: SPST(SPST)-Normal Open
Number of Channels: 1
On-State Resistance (Max): 10Ω
Package: SC-70-5
Manufacturer: Texas Instruments
Charge Injection: 2pC
Voltage - Supply, Dual (V±): -
Crosstalk: -
Base Part Number: MAX4596
Operating Temperature: -40°C ~ 85°C (TA)
Switch Time (Ton, Toff) (Max): 35ns, 40ns
Multiplexer/Demultiplexer Circuit: 1:1
Package / Case: 5-TSSOP, SC-70-5, SOT-353
Channel Capacitance (CS(off), CD(off)): 8pF, 8pF
Channel-to-Channel Matching (ΔRon): -
Supplier Device Package: SC-70-5
Series: -
Current - Leakage (IS(off)) (Max): 500pA
Number of Circuits: 1
Part Status: Active
Mounting Type: Surface Mount
Voltage - Supply, Single (V+): 2.4V ~ 5.5V
-3db Bandwidth: 300MHz
Packaging: Cut Tape (CT)
detail: 1 Circuit IC Switch 1:1 10Ohm SC-70-5
