TS5A3154YZPR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TS5A3154YZPR	دانلود دیتاشیت

TS5A3154 30 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TS5A3154YZPR
Turn-on time: 16ns
Turn-off time: 15ns
Supply Voltage: 1.65V~5.5V
Switch Circuit: SPDT(SPDT)
Number of Channels: 1
On-State Resistance (Max): 900mΩ
Package: BGA-8
Manufacturer: Texas Instruments
Charge Injection: 12pC
Voltage - Supply, Dual (V±): -
Crosstalk: -64dB @ 1MHz
Base Part Number: TS5A315
Operating Temperature: -40°C ~ 85°C (TA)
Switch Time (Ton, Toff) (Max): 16ns, 15ns
Multiplexer/Demultiplexer Circuit: 2:1
Package / Case: 8-XFBGA, DSBGA
Channel Capacitance (CS(off), CD(off)): 19pF, 36pF
Channel-to-Channel Matching (ΔRon): 50mOhm
Supplier Device Package: 8-DSBGA, 8-WCSP (1.9x0.9)
Series: -
Current - Leakage (IS(off)) (Max): 20nA
Number of Circuits: 1
Part Status: Active
Mounting Type: Surface Mount
Voltage - Supply, Single (V+): 1.65V ~ 5.5V
-3db Bandwidth: 100MHz
Packaging: Cut Tape (CT)
detail: 1 Circuit IC Switch 2:1 900mOhm 8-DSBGA, 8-WCSP (1.9x0.9)
