دیتاشیت AT91RM9200-QU-002
مشخصات دیتاشیت
| نام دیتاشیت | AT91RM9200 Summary |
|---|---|
| حجم فایل | 781.919 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 41 |
دانلود دیتاشیت AT91RM9200 Summary |
AT91RM9200 Summary Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: -
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 48KB
- Watchdog: -
- ADC (Bit): -
- DAC (Bit): -
- Datasheet: Microchip Tech AT91RM9200-QU-002
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 180MHz
- GPIO Ports Number: 122
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: -
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 128KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.65V~1.95V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: QFN-208(28x28)
- Manufacturer: Microchip Tech
- Series: AT91
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM920T
- Core Size: 16/32-Bit
- Speed: 180MHz
- Connectivity: EBI/EMI, Ethernet, I²C, Memory Card, SPI, SSC, UART/USART, USB
- Peripherals: POR
- Number of I/O: 122
- Program Memory Size: 128KB (128K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.65V ~ 1.95V
- Data Converters: -
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 208-BFQFP
- Supplier Device Package: 208-PQFP (28x28)
- Base Part Number: AT91RM9200
- detail: ARM920T AT91 Microcontroller IC 16/32-Bit 180MHz 128KB (128K x 8) ROM 208-PQFP (28x28)
