دیتاشیت TC1185-3.0VCT713
مشخصات دیتاشیت
| نام دیتاشیت | TC1185-3.0VCT713 |
|---|---|
| حجم فایل | 64.204 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 21 |
TC1185-3.0VCT713 |
دانلود دیتاشیت |
|---|
سایر مستندات
Analog and Interface Product Guide 76 pages
TC1014, 1015, 1185 22 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech TC1185-3.0VCT713
- Output Type: Fixed
- Output Current: 150mA
- Output Voltage: 3V
- Dropout Voltage: 400mV@(150mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 6V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 80uA
- Power Supply Rejection Ratio (PSRR): 64dB@(1kHz)
- Package: SOT-23-5
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 6V
- Voltage - Output (Min/Fixed): 3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.4V @ 150mA
- Current - Output: 150mA
- Current - Quiescent (Iq): 80µA
- PSRR: 64dB (1kHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature
- Mounting Type: Surface Mount
- Package / Case: SC-74A, SOT-753
- Supplier Device Package: SOT-23-5
- Base Part Number: TC1185
- detail: Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
