دیتاشیت MIC5203-3.3YM5-TR
مشخصات دیتاشیت
| نام دیتاشیت | MIC5203 |
|---|---|
| حجم فایل | 266.602 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت MIC5203 |
MIC5203 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech MIC5203-3.3YM5-TR
- Output Type: Fixed
- Output Current: 80mA
- Output Voltage: 3.3V
- Dropout Voltage: 600mV@(80mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 16V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 750uA
- Power Supply Rejection Ratio (PSRR): -
- Package: SOT-23-5
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 16V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.6V @ 80mA
- Current - Output: 80mA
- Current - Quiescent (Iq): 750µA
- Current - Supply (Max): 3mA
- PSRR: -
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Reverse Polarity
- Mounting Type: Surface Mount
- Package / Case: SC-74A, SOT-753
- Supplier Device Package: SOT-23-5
- Base Part Number: MIC5203
- detail: Linear Voltage Regulator IC 1 Output 80mA SOT-23-5
