دیتاشیت TLV2217-25PWR
مشخصات دیتاشیت
| نام دیتاشیت |
TLV2217
|
| حجم فایل |
1186.634
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
23
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TLV2217-25PWR
-
Output Current:
500mA
-
Output Voltage:
2.5V~2.5V
-
Dropout Voltage:
0.5V@(500mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
12V
-
Operating Temperature:
0°C~+125°C
-
Power Supply Rejection Ratio (PSRR):
62dB@(120Hz)
-
Package:
TSSOP-20
-
Manufacturer:
Texas Instruments
-
Series:
-
-
Voltage Dropout (Max):
0.5V @ 500mA
-
Package / Case:
20-TSSOP (0.173", 4.40mm Width)
-
Base Part Number:
TLV221
-
Supplier Device Package:
20-TSSOP
-
Current - Output:
500mA
-
PSRR:
62dB (120Hz)
-
Part Status:
Active
-
Voltage - Input (Max):
12V
-
Mounting Type:
Surface Mount
-
Control Features:
-
-
Protection Features:
Over Current, Over Temperature, Over Voltage
-
Voltage - Output (Min/Fixed):
2.5V
-
Voltage - Output (Max):
-
-
Packaging:
Cut Tape (CT)
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Output Type:
Fixed
-
detail:
Linear Voltage Regulator IC 1 Output 500mA 20-TSSOP
