ADCMP608BKSZ-REEL7 دیتاشیت

ADCMP608BKSZ-REEL7

مشخصات دیتاشیت

نام دیتاشیت ADCMP608BKSZ-REEL7
حجم فایل 78.705 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

مشاهده دیتاشیت ADCMP608BKSZ-REEL7

دانلود دیتاشیت

سایر مستندات

ADCMP608 10 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Analog Devices ADCMP608BKSZ-REEL7
  • Output Type: CMOS;轨到轨;TTL
  • Supply Current: 1.3mA
  • Supply Voltage: 2.5V~5.5V
  • Number of Elements: 1
  • Operating Temperature: -40°C~+125°C
  • Propagation Delay Time: 60ns
  • Input Bias Current (Ib): 0.4uA
  • Input Offset Voltage (Vos): 3mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): 45dB
  • Package: SC-70-6
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: General Purpose
  • Voltage - Supply, Single/Dual (±): 2.5V ~ 5.5V
  • Voltage - Input Offset (Max): 3mV @ 2.5V
  • Current - Input Bias (Max): 0.4µA @ 2.5V
  • Current - Output (Typ): 50mA
  • Current - Quiescent (Max): 1.3mA
  • CMRR, PSRR (Typ): 45dB CMRR, 50dB PSRR
  • Propagation Delay (Max): 60ns
  • Hysteresis: -
  • Package / Case: 6-TSSOP, SC-88, SOT-363
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-70-6
  • Base Part Number: ADCMP608
  • detail: Comparator General Purpose CMOS, Rail-to-Rail, TTL SC-70-6
