دیتاشیت ADP1708ARDZ-R7

ADP1706-08

مشخصات دیتاشیت

نام دیتاشیت ADP1706-08
حجم فایل 530.522 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت ADP1706-08

ADP1706-08 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 0.8V
  • Voltage - Output (Max): 5V
  • Voltage Dropout (Max): 0.6V @ 1A
  • Current - Output: 1A
  • Current - Quiescent (Iq): 390µA
  • Current - Supply (Max): 1.55mA
  • PSRR: 70dB ~ 56dB (1kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
  • Supplier Device Package: 8-SOIC-EP
  • Base Part Number: ADP1708
  • detail: Linear Voltage Regulator IC 1 Output 1A 8-SOIC-EP
