MIC5309YMT-TR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MIC5309YMT-TR
|
|
حجم فایل
|
83.166
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Microchip Tech MIC5309YMT-TR
-
Output Type:
Adjustable
-
Output Current:
300mA
-
Output Voltage:
0.8V~2V
-
Dropout Voltage:
200mV@(300mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C
-
Power Supply Rejection Ratio (PSRR):
90dB@(1kHz),80dB@(20kHz)
-
Package:
TMLF-6
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
0.8V
-
Voltage - Output (Max):
2V
-
Voltage Dropout (Max):
0.2V @ 300mA
-
Current - Output:
300mA
-
PSRR:
90dB ~ 70dB (1kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
6-UFDFN Exposed Pad, 6-TMLF®
-
Supplier Device Package:
6-TMLF® (1.6x1.6)
-
Base Part Number:
MIC5309
-
detail:
Linear Voltage Regulator IC 1 Output 300mA 6-TMLF® (1.6x1.6)
