دیتاشیت ADG5436FBRUZ

مشخصات دیتاشیت

دانلود دیتاشیت ADG5436F Datasheet	ADG5436F Datasheet Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG5436FBRUZ
Turn-on time: 535ns
Turn-off time: 205ns
Supply Voltage: 8V~44V
Switch Circuit: SPDT(SPDT)
Number of Channels: 2
On-State Resistance (Max): 11.5Ω
Package: TSSOP-16
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Multiplexer/Demultiplexer Circuit: 2:1
Number of Circuits: 2
Channel-to-Channel Matching (ΔRon): 150mOhm
Voltage - Supply, Single (V+): 8V ~ 44V
Voltage - Supply, Dual (V±): ±5V ~ 22V
Switch Time (Ton, Toff) (Max): 535ns, 205ns
-3db Bandwidth: 171MHz
Charge Injection: -737pC
Channel Capacitance (CS(off), CD(off)): 11pF, 23pF
Current - Leakage (IS(off)) (Max): 500pA
Crosstalk: -73dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package: 16-TSSOP
Base Part Number: ADG5436
detail: 2 Circuit IC Switch 2:1 11.5Ohm 16-TSSOP
