دیتاشیت ADG658YRUZ-REEL7
مشخصات دیتاشیت
| نام دیتاشیت |
ADG658,59
|
| حجم فایل |
397.453
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
20
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices ADG658YRUZ-REEL7
-
Turn-on time:
115ns
-
Turn-off time:
45ns
-
Supply Voltage:
2V~12V
-
Switch Circuit:
-
-
Number of Channels:
1
-
On-State Resistance (Max):
75Ω
-
Package:
TSSOP-16
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Multiplexer/Demultiplexer Circuit:
8:1
-
Number of Circuits:
1
-
Channel-to-Channel Matching (ΔRon):
1.3Ohm
-
Voltage - Supply, Single (V+):
2V ~ 12V
-
Voltage - Supply, Dual (V±):
±2V ~ 6V
-
Switch Time (Ton, Toff) (Max):
115ns, 45ns
-
-3db Bandwidth:
210MHz
-
Charge Injection:
2pC
-
Channel Capacitance (CS(off), CD(off)):
4pF, 23pF
-
Current - Leakage (IS(off)) (Max):
200pA
-
Crosstalk:
-
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
16-TSSOP
-
Base Part Number:
ADG658
-
detail:
1 Circuit IC Switch 8:1 75Ohm 16-TSSOP
