دیتاشیت Signal e-Book: OP Amp Design Topics

Signal e-Book: OP Amp Design Topics

مشخصات دیتاشیت

نام دیتاشیت Signal e-Book: OP Amp Design Topics
حجم فایل 17975.467 کیلوبایت
نوع فایل pdf
تعداد صفحات 37

Signal e-Book: OP Amp Design Topics

دانلود دیتاشیت

سایر مستندات

LF356H 28 pages

LF356 Datasheet 28 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/FET InputAmplifiers
  • Datasheet: Texas Instruments LF356 MWC
  • Number of Circuits: 1
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): 30pA
  • Gain Bandwidth Product(GBP): 5MHz
  • Voltage - Input Offset(Vos): 3mV
  • Package: -
  • Manufacturer: Texas Instruments
  • Series: BI-FET™
  • Package / Case: Die
  • Current - Supply: 5mA
  • Voltage - Input Offset: 3mV
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Slew Rate: 12V/µs
  • Voltage - Supply, Single/Dual (±): 10V ~ 36V, ±5V ~ 18V
  • Gain Bandwidth Product: 5MHz
  • Amplifier Type: J-FET
  • Packaging: Bulk
  • Base Part Number: LF356
  • Current - Input Bias: 30pA
  • Output Type: -
  • Supplier Device Package: Wafersale
  • detail: J-FET Amplifier 1 Circuit Wafersale
