LM2901 MWA Datasheet
Datasheet specifications
| Datasheet's name | LM2901 |
|---|---|
| File size | 751.165 KB |
| File type | |
| Number of pages | 23 |
Download Datasheet LM2901 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Series: -
- Type: General Purpose
- Package / Case: Die
- Number of Elements: 4
- Voltage - Input Offset (Max): 7mV @ 30V
- Current - Output (Typ): 16mA @ 5V
- Part Status: Active
- Base Part Number: LM2901
- Mounting Type: Surface Mount
- Operating Temperature: -40°C ~ 85°C
- Voltage - Supply, Single/Dual (±): 2V ~ 36V, ±1V ~ 18V
- Manufacturer: Texas Instruments
- Propagation Delay (Max): -
- Current - Input Bias (Max): 0.25µA @ 5V
- Hysteresis: -
- Packaging: Bulk
- CMRR, PSRR (Typ): -
- Current - Quiescent (Max): 2.5mA
- Output Type: CMOS, DTL, ECL, MOS, Open-Collector, TTL
- Supplier Device Package: Wafersale
- detail: Comparator General Purpose CMOS, DTL, ECL, MOS, Open-Collector, TTL Wafersale
