دیتاشیت INA2181A1QDGSRQ1
مشخصات دیتاشیت
| نام دیتاشیت | INA181-Q1, INA,2181-Q1, INA4181-Q1 |
|---|---|
| حجم فایل | 2324.508 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 49 |
دانلود دیتاشیت INA181-Q1, INA,2181-Q1, INA4181-Q1 |
INA181-Q1, INA,2181-Q1, INA4181-Q1 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Current-Sensing Amplifiers
- Datasheet: Texas Instruments INA2181A1QDGSRQ1
- Supply Current: 356uA
- Number of Channels: 2
- Operating Temperature: -40°C~+125°C
- Package: VSSOP-10
- Manufacturer: Texas Instruments
- Series: Automotive, AEC-Q100
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Number of Circuits: 2
- Current - Supply: 356µA
- Voltage - Input Offset: 100µV
- Mounting Type: Surface Mount
- Part Status: Active
- Slew Rate: 2V/µs
- Voltage - Supply, Single/Dual (±): 2.7V ~ 5.5V
- Gain Bandwidth Product: 350kHz
- Amplifier Type: Current Sense
- -3db Bandwidth: 350kHz
- Packaging: Cut Tape (CT)
- Base Part Number: INA218
- Current - Input Bias: 75µA
- Output Type: Rail-to-Rail
- Supplier Device Package: 10-VSSOP
- detail: Current Sense Amplifier 2 Circuit Rail-to-Rail 10-VSSOP
