ADF4002BRUZ-RL7 Datasheet
Datasheet specifications
| Datasheet's name | ADF4002BRUZ-RL7 |
|---|---|
| File size | 77.419 KB |
| File type | |
| Number of pages | 21 |
Download Datasheet ADF4002BRUZ-RL7 |
Download Datasheet |
|---|
Other documentations
ADF4002 20 pages
Technical specifications
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Detectors
- Datasheet: Analog Devices ADF4002BRUZ-RL7
- Package: TSSOP-16
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Clock/Frequency Synthesizer (RF), Phase Detector
- PLL: Yes with Bypass
- Input: CMOS, TTL
- Output: Clock
- Number of Circuits: 1
- Ratio - Input:Output: 2:1
- Differential - Input:Output: Yes/No
- Frequency - Max: 400MHz
- Divider/Multiplier: Yes/No
- Voltage - Supply: 2.7V ~ 3.3V
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 16-TSSOP
- Base Part Number: ADF4002
- detail: IC PLL FREQUENCY SYNTH 16-TSSOP
