دیتاشیت ADG1608BCPZ-REEL7

ADG1608,09

مشخصات دیتاشیت

نام دیتاشیت ADG1608,09
حجم فایل 480.254 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت ADG1608,09

ADG1608,09 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Circuit: -
  • Multiplexer/Demultiplexer Circuit: 8:1
  • Number of Circuits: 1
  • On-State Resistance (Max): 4.5Ohm
  • Channel-to-Channel Matching (ΔRon): 120mOhm
  • Voltage - Supply, Single (V+): 3.3V ~ 16V
  • Voltage - Supply, Dual (V±): ±3.3V ~ 8V
  • Switch Time (Ton, Toff) (Max): 94ns, 93ns
  • -3db Bandwidth: 40MHz
  • Charge Injection: 29pC
  • Channel Capacitance (CS(off), CD(off)): 19pF, 117pF
  • Current - Leakage (IS(off)) (Max): 100pA
  • Crosstalk: -64dB @ 1MHz
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 16-WFQFN Exposed Pad, CSP
  • Supplier Device Package: 16-LFCSP-WQ (3x3)
  • Base Part Number: ADG1608
  • detail: 1 Circuit IC Switch 8:1 4.5Ohm 16-LFCSP-WQ (3x3)
