دیتاشیت ADUM7440CRQZ-RL7
مشخصات دیتاشیت
| نام دیتاشیت |
ADuM7440-42
|
| حجم فایل |
401.713
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
20
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
iCoupler®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Technology:
Magnetic Coupling
-
Type:
General Purpose
-
Isolated Power:
No
-
Number of Channels:
4
-
Inputs - Side 1/Side 2:
4/0
-
Channel Type:
Unidirectional
-
Voltage - Isolation:
1000Vrms
-
Common Mode Transient Immunity (Min):
15kV/µs
-
Data Rate:
25Mbps
-
Propagation Delay tpLH / tpHL (Max):
50ns, 50ns
-
Pulse Width Distortion (Max):
5ns
-
Rise / Fall Time (Typ):
2ns, 2ns
-
Voltage - Supply:
3V ~ 5.5V
-
Operating Temperature:
-40°C ~ 105°C
-
Mounting Type:
Surface Mount
-
Package / Case:
16-SSOP (0.154", 3.90mm Width)
-
Supplier Device Package:
16-QSOP
-
Base Part Number:
ADUM7440
-
detail:
General Purpose Digital Isolator 1000Vrms 4 Channel 25Mbps 15kV/µs CMTI 16-SSOP (0.154", 3.90mm Width)
