ADA4084-2ACPZ-R7 数据手册
其他文档
ADA4084-1,2,4 36 pages
技术规格
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: Analog Devices ADA4084-2ACPZ-R7
- Rail to Rail: 轨到轨
- -3db Bandwidth: 13.9MHz
- Output Current: 30mA
- Operating Temperature: -40°C~+125°C
- Current - Input Bias(Ib): 140nA
- Gain Bandwidth Product(GBP): 15.9MHz
- Package: LFCSP-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Amplifier Type: General Purpose
- Number of Circuits: 2
- Output Type: Rail-to-Rail
- Slew Rate: 4.6V/µs
- Gain Bandwidth Product: 15.9MHz
- Current - Input Bias: 140nA
- Voltage - Input Offset: 130µV
- Current - Supply: 625µA
- Current - Output / Channel: 30mA
- Voltage - Supply, Single/Dual (±): 3V ~ 30V, ±1.5V ~ 15V
- Mounting Type: Surface Mount
- Package / Case: 8-WFDFN Exposed Pad, CSP
- Supplier Device Package: 8-LFCSP-WD (3x3)
- Base Part Number: ADA4084
- detail: General Purpose Amplifier 2 Circuit Rail-to-Rail 8-LFCSP-WD (3x3)
