دیتاشیت MCP4822-E/P
مشخصات دیتاشیت
| نام دیتاشیت | MCP4802,4812,4822 Datasheet |
|---|---|
| حجم فایل | 1666.028 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 50 |
دانلود دیتاشیت MCP4802,4812,4822 Datasheet |
MCP4802,4812,4822 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
- Datasheet: Microchip Tech MCP4822-E/P
- Interface: SPI
- Resolution: 12Bit
- Output Type: Voltage-缓冲
- Settling Time: 4.5us
- Supply Voltage: 2.7V~5.5V
- Integral nonlinearity: ±4LSB;±0.25LSB
- Operating Temperature: -40°C~+125°C
- Package: PDIP-8
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Number of Bits: 12
- Number of D/A Converters: 2
- Differential Output: No
- Data Interface: SPI
- Reference Type: Internal
- Voltage - Supply, Analog: 2.7V ~ 5.5V
- Voltage - Supply, Digital: 2.7V ~ 5.5V
- INL/DNL (LSB): ±4, ±0.25
- Architecture: String DAC
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-PDIP
- Mounting Type: Through Hole
- Base Part Number: MCP4822
- detail: 12 Bit Digital to Analog Converter 2 8-PDIP
