دیتاشیت ADUM3151BRSZ-RL7
مشخصات دیتاشیت
نام دیتاشیت |
ADuM3151/2/3
|
حجم فایل |
423.986
کیلوبایت
|
نوع فایل |
pdf
|
تعداد صفحات |
22
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Digital Isolators
-
Data Rate:
34Mbps
-
Datasheet:
Analog Devices ADUM3151BRSZ-RL7
-
Applications:
SPI
-
Supply Voltage:
3V~5.5V
-
Forward Channel:
5
-
Reverse channel:
2
-
Number of Channels:
7
-
Isolation Technology:
Magnetic isolation
-
Operating Temperature:
-40°C~+125°C
-
Voltage Isolation or Not:
Without voltage isolation
-
Package:
SSOP-20-208mil
-
Manufacturer:
Analog Devices
-
Series:
iCoupler®, SPIsolator™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Technology:
Magnetic Coupling
-
Type:
SPI
-
Isolated Power:
No
-
Inputs - Side 1/Side 2:
5/2
-
Channel Type:
Unidirectional
-
Voltage - Isolation:
3750Vrms
-
Common Mode Transient Immunity (Min):
25kV/µs
-
Propagation Delay tpLH / tpHL (Max):
14ns, 14ns
-
Pulse Width Distortion (Max):
2ns
-
Rise / Fall Time (Typ):
2.5ns, 2.5ns
-
Voltage - Supply:
3V ~ 5.5V
-
Mounting Type:
Surface Mount
-
Package / Case:
20-SSOP (0.209", 5.30mm Width)
-
Supplier Device Package:
20-SSOP
-
Base Part Number:
ADUM3151
-
detail:
SPI Digital Isolator 3750Vrms 7 Channel 34Mbps 25kV/µs CMTI 20-SSOP (0.209", 5.30mm Width)
