TPS6125x Datasheet دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPS6125x Datasheet	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType
Topology: Boost
Datasheet: Texas Instruments TPS612592YFFR
Output Type: Fixed
Input Voltage: 2.65V~4.85V
Output Voltage: 5.2V
Number of Outputs: 1
Switching Frequency: 3.5MHz
Output Current (Max): 3.9A
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: Yes
Package: DSBGA-9(1.2x1.3)
Manufacturer: Texas Instruments
Series: -
Voltage - Input (Min): 2.65V
Base Part Number: TPS612
Current - Output: 3.9A (Switch)
Frequency - Switching: 3.5MHz
Part Status: Active
Voltage - Input (Max): 4.85V
Mounting Type: Surface Mount
Supplier Device Package: 9-DSBGA (1.2x1.3)
Voltage - Output (Min/Fixed): 5.2V
Package / Case: 9-UFBGA, DSBGA
Voltage - Output (Max): -
Packaging: Cut Tape (CT)
Output Configuration: Positive
Synchronous Rectifier: Yes
detail: Boost Switching Regulator IC Positive Fixed 5.2V 1 Output 3.9A (Switch) 9-UFBGA, DSBGA
