دیتاشیت ADG821BRMZ-REEL7
مشخصات دیتاشیت
| نام دیتاشیت |
ADG821-823
|
| حجم فایل |
214.079
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices ADG821BRMZ-REEL7
-
Turn-on time:
45ns
-
Turn-off time:
16ns
-
Supply Voltage:
1.8V~5.5V
-
Switch Circuit:
SPST(SPST)-Normal Open
-
Number of Channels:
2
-
On-State Resistance (Max):
600mΩ
-
Package:
MSOP-8
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Number of Circuits:
2
-
Channel-to-Channel Matching (ΔRon):
160mOhm
-
Voltage - Supply, Single (V+):
1.8V ~ 5.5V
-
Voltage - Supply, Dual (V±):
-
-
Switch Time (Ton, Toff) (Max):
45ns, 16ns
-
-3db Bandwidth:
24MHz
-
Charge Injection:
15pC
-
Channel Capacitance (CS(off), CD(off)):
85pF, 98pF
-
Current - Leakage (IS(off)) (Max):
250pA
-
Crosstalk:
-82dB @ 1MHz
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
8-MSOP
-
Base Part Number:
ADG821
-
detail:
2 Circuit IC Switch 1:1 600mOhm 8-MSOP
