دیتاشیت UCC37322DGNRG4

UCC27321-22, UCC37321-22

مشخصات دیتاشیت

نام دیتاشیت UCC27321-22, UCC37321-22
حجم فایل 1666.036 کیلوبایت
نوع فایل pdf
تعداد صفحات 36

دانلود دیتاشیت UCC27321-22, UCC37321-22

UCC27321-22, UCC37321-22 Datasheet

مشخصات

  • Series: -
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
  • Current - Peak Output (Source, Sink): 9A, 9A
  • Base Part Number: UCC373
  • Channel Type: Single
  • Rise / Fall Time (Typ): 20ns, 20ns
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Manufacturer: Texas Instruments
  • Logic Voltage - VIL, VIH: 1.1V, 2.7V
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Number of Drivers: 1
  • Gate Type: N-Channel, P-Channel MOSFET
  • Voltage - Supply: 4V ~ 15V
  • Driven Configuration: Low-Side
  • Packaging: Tape & Reel (TR)
  • Input Type: Non-Inverting
  • Supplier Device Package: 8-MSOP-PowerPad
  • detail: Low-Side Gate Driver IC Non-Inverting 8-MSOP-PowerPad
