ADG5207BCPZ-RL7 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ADG5207BCPZ-RL7	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG5207BCPZ-RL7
Turn-on time: 230ns
Turn-off time: 185ns
Supply Voltage: 9V~40V
Number of Channels: 2
On-State Resistance (Max): 160Ω
Package: LFCSP-32
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Switch Circuit: -
Multiplexer/Demultiplexer Circuit: 8:1
Number of Circuits: 2
Channel-to-Channel Matching (ΔRon): 4Ohm
Voltage - Supply, Single (V+): 9V ~ 40V
Voltage - Supply, Dual (V±): ±9V ~ 22V
Switch Time (Ton, Toff) (Max): 230ns, 185ns
-3db Bandwidth: 145MHz
Charge Injection: 0.45pC
Channel Capacitance (CS(off), CD(off)): 3.3pf, 32pF
Current - Leakage (IS(off)) (Max): 100pA
Crosstalk: -76dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 32-WFQFN Exposed Pad, CSP
Supplier Device Package: 32-LFCSP (5x5)
Base Part Number: ADG5207
detail: 2 Circuit IC Switch 8:1 160Ohm 32-LFCSP (5x5)
