دیتاشیت LP38690SD-2.5/NOPB

LP38690, LP38692 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LP38690, LP38692 Datasheet
حجم فایل 2035.583 کیلوبایت
نوع فایل pdf
تعداد صفحات 33

دانلود دیتاشیت LP38690, LP38692 Datasheet

LP38690, LP38692 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LP38690SD-2.5/NOPB
  • Package: DFN-6(3x3)
  • Manufacturer: Texas Instruments
  • Control Features: -
  • Base Part Number: LP38690
  • Package / Case: 6-WDFN Exposed Pad
  • Current - Supply (Max): 100µA
  • Part Status: Obsolete
  • Current - Output: 1A
  • PSRR: 55dB (120Hz)
  • Series: -
  • Voltage - Output (Min/Fixed): 2.5V
  • Mounting Type: Surface Mount
  • Number of Regulators: 1
  • Current - Quiescent (Iq): 55µA
  • Output Configuration: Positive
  • Voltage Dropout (Max): 1.3V @ 1A
  • Operating Temperature: -40°C ~ 125°C
  • Supplier Device Package: 6-WSON (3x3)
  • Protection Features: Over Temperature
  • Voltage - Input (Max): 10V
  • Output Type: Fixed
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Max): -
  • detail: Linear Voltage Regulator IC 1 Output 1A 6-WSON (3x3)
