ADG408,409 数据手册
其他文档
ADG408BNZ 15 pages
技术规格
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices ADG409BNZ
- Supply Voltage: 12V
- Switch Circuit: 单刀四掷(SP4T)
- Number of Channels: 2
- On-State Resistance (Max): 100Ω
- Package: PDIP-16
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Multiplexer/Demultiplexer Circuit: 4:1
- Number of Circuits: 2
- Channel-to-Channel Matching (ΔRon): 15Ohm (Max)
- Voltage - Supply, Single (V+): 12V
- Voltage - Supply, Dual (V±): ±15V
- Switch Time (Ton, Toff) (Max): -
- -3db Bandwidth: -
- Charge Injection: 20pC
- Channel Capacitance (CS(off), CD(off)): 11pF, 20pF
- Current - Leakage (IS(off)) (Max): 500pA
- Crosstalk: -85dB @ 100kHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Through Hole
- Package / Case: 16-DIP (0.300", 7.62mm)
- Supplier Device Package: 16-PDIP
- Base Part Number: ADG409
- detail: 2 Circuit IC Switch 4:1 100Ohm 16-PDIP
