CMP401GSZ دیتاشیت

CMP401GSZ

مشخصات دیتاشیت

نام دیتاشیت CMP401GSZ
حجم فایل 66.329 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت CMP401GSZ

دانلود دیتاشیت

سایر مستندات

CMP401,402 8 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Analog Devices CMP401GSZ
  • Output Type: Push Pull
  • Supply Voltage: 5V
  • Number of Elements: -
  • Operating Temperature: -40°C~+125°C
  • Input Bias Current (Ib): 3uA
  • Input Offset Voltage (Vos): 3mV
  • Input Hysteresis Voltage (Vhys): 2mV
  • Common Mode Rejection Ratio (CMRR): 74dB
  • Package: SOIC-16
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Type: General Purpose
  • Voltage - Supply, Single/Dual (±): ±5V
  • Voltage - Input Offset (Max): 3mV @ 5V
  • Current - Input Bias (Max): 3µA @ 5V
  • Current - Output (Typ): -
  • Current - Quiescent (Max): 6mA,1mA
  • CMRR, PSRR (Typ): 60dB CMRR, 60dB PSRR
  • Propagation Delay (Max): 30ns
  • Hysteresis: 2mV
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 16-SOIC
  • Base Part Number: CMP0401
  • detail: Comparator General Purpose CMOS, TTL 16-SOIC
