LM5110-3MX/NOPB Datasheet

LM5110-3MX/NOPB

Datasheet specifications

Datasheet's name LM5110-3MX/NOPB
File size 103.279 KB
File type pdf
Number of pages 29

Download Datasheet LM5110-3MX/NOPB

Download Datasheet

Other documentations

LM5110 Datasheet 28 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Texas Instruments LM5110-3SD/NOPB
  • Package: DFN-10(4x4)
  • Manufacturer: Texas Instruments
  • Series: -
  • Package / Case: 10-WDFN Exposed Pad
  • Current - Peak Output (Source, Sink): 3A, 5A
  • Base Part Number: LM5110
  • Channel Type: Independent
  • Rise / Fall Time (Typ): 14ns, 12ns
  • Part Status: Not For New Designs
  • Mounting Type: Surface Mount
  • Logic Voltage - VIL, VIH: 0.8V, 2.2V
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Number of Drivers: 2
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 3.5V ~ 14V
  • Driven Configuration: Low-Side
  • Packaging: Cut Tape (CT)
  • Input Type: Inverting, Non-Inverting
  • Supplier Device Package: 10-WSON (4x4)
  • detail: Low-Side Gate Driver IC Inverting, Non-Inverting 10-WSON (4x4)
