ADG5404FBRUZ-RL7 دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت ADG5404FBRUZ-RL7	دانلود دیتاشیت

ADG5404F 30 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG5404FBRUZ-RL7
Turn-on time: 535ns
Turn-off time: 205ns
Supply Voltage: 8V~44V
Number of Channels: 1
On-State Resistance (Max): 11.5Ω
Package: TSSOP-14
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Switch Circuit: -
Multiplexer/Demultiplexer Circuit: 4:1
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 650mOhm
Voltage - Supply, Single (V+): 8V ~ 44V
Voltage - Supply, Dual (V±): ±5V ~ 22V
Switch Time (Ton, Toff) (Max): 535ns, 205ns
-3db Bandwidth: 110MHz
Charge Injection: 695pC
Channel Capacitance (CS(off), CD(off)): 11pF, 47pF
Current - Leakage (IS(off)) (Max): 500pA
Crosstalk: -73dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 14-TSSOP (0.173", 4.40mm Width)
Supplier Device Package: 14-TSSOP
Base Part Number: ADG5404
detail: 1 Circuit IC Switch 4:1 11.5Ohm 14-TSSOP
