دیتاشیت AD7298-1BCPZ
مشخصات دیتاشیت
| نام دیتاشیت |
AD7298-1
|
| حجم فایل |
750.946
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
24
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
-
Datasheet:
Analog Devices AD7298-1BCPZ
-
Interface:
SPI;DSP
-
resolution:
10Bit
-
Supply Voltage:
2.8V~3.6V
-
number of channels:
8
-
sampling frequency:
1MHz
-
Operating Temperature:
-40°C~+125°C
-
Package:
LFCSP-20
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tray
-
Part Status:
Active
-
Number of Bits:
10
-
Sampling Rate (Per Second):
1M
-
Number of Inputs:
8
-
Input Type:
Single Ended
-
Data Interface:
SPI, DSP
-
Configuration:
MUX-S/H-ADC
-
Ratio - S/H:ADC:
1:1
-
Number of A/D Converters:
1
-
Architecture:
SAR
-
Reference Type:
External, Internal
-
Voltage - Supply, Analog:
2.8V ~ 3.6V
-
Voltage - Supply, Digital:
2.8V ~ 3.6V
-
Features:
Temperature Sensor
-
Package / Case:
20-WFQFN Exposed Pad, CSP
-
Supplier Device Package:
20-LFCSP-WQ (4x4)
-
Mounting Type:
Surface Mount
-
Base Part Number:
AD7298
-
detail:
10 Bit Analog to Digital Converter 8 Input 1 SAR 20-LFCSP-WQ (4x4)
