دیتاشیت ATWINC1500-MR210PB1961

مشخصات دیتاشیت

دانلود دیتاشیت ATWINC15x0-MR210xBB	ATWINC15x0-MR210xBB Datasheet

Manufacturer: Microchip Technology
Series: SmartConnect
Part Status: Active
RF Family/Standard: WiFi
Protocol: 802.11b/g/n
Modulation: 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Frequency: 2.4GHz
Data Rate: 72.2Mbps
Power - Output: 18.5dBm
Sensitivity: -95dBm
Serial Interfaces: I²C, SPI, UART
Antenna Type: Integrated, Trace
Utilized IC / Part: ATWINC1500
Memory Size: 4MB Flash, 128kB RAM
Voltage - Supply: 2.7V ~ 3.6V
Current - Receiving: 61mA
Current - Transmitting: 265mA
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C
Package / Case: 28-SMD Module
Firmware Version: 19.6.1
detail: WiFi 802.11b/g/n Transceiver Module 2.4GHz Integrated, Trace Surface Mount
