HMC510LP5ETR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
HMC510LP5ETR
|
|
حجم فایل
|
97.239
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
RoHS:
true
-
Category:
RTC/Clock Chip/Clock Generators / Frequency Synthesizers / PLL
-
Datasheet:
Analog Devices HMC510LP5ETR
-
Package:
VFQFN-32-EP(5x5)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Frequency Range:
4.225 ~ 4.775GHz, 8.45 ~ 9.55GHz
-
Frequency - Center:
4.5GHz, 9GHz
-
Voltage - Supply:
5V
-
Tuning Voltage (VDC):
2V ~ 13V
-
2nd Harmonic, Typ (dBc):
15
-
Icc Max:
360mA
-
Pushing (MHz/V):
20
-
Power (dBm):
-6±2, 11±3, 12.5±2.5
-
Phase Noise Typ (dBc/Hz):
-116
-
Operating Temperature:
-40°C ~ 85°C
-
Package / Case:
32-VFQFN Exposed Pad, CSP
-
Size / Dimension:
0.197" L x 0.197" W (5.00mm x 5.00mm)
-
Height:
0.039" (1.00mm)
-
Base Part Number:
HMC510
-
detail:
4.5GHz, 9GHz Center Frequency 2V ~ 13V Voltage Controlled Oscillator -6±2, 11±3, 12.5±2.5 dBm 15 2nd Harmonic, Typ (dBc)
